Electro Mechanical Servo Control Universal Testing Machine (Double Column)

Electro Mechanical Servo Control Universal Testing Machine (Double Column)

Product Details:

  • Power 50Hz Volt (v)
  • Power Supply AC220V10%, 50Hz
  • Voltage AC220 Volt (v)
  • Machine Weight 160 to 800 Kilograms (kg)
  • Test Width 400 to 550 Millimeter (mm)
1 INR/Number
X

Electro Mechanical Servo Control Universal Testing Machine (Double Column) Price And Quantity

  • 1 INR/Number
  • 1 Bottle

Electro Mechanical Servo Control Universal Testing Machine (Double Column) Product Specifications

  • AC220V10%, 50Hz
  • AC220 Volt (v)
  • 400 to 550 Millimeter (mm)
  • 160 to 800 Kilograms (kg)
  • 50Hz Volt (v)

Electro Mechanical Servo Control Universal Testing Machine (Double Column) Trade Information

  • Cheque Telegraphic Transfer (T/T)
  • 1 Bottle Per Week
  • 1 Week
  • All India

Product Description

Features


1.Digital Display: During the whole testing process, the LCD real time display the testing force, peak value, displacement, testing speed and testing force - time curve, testing force - displacement curves.

2.Automatic Return: Beam automatically return to initial position when testing finished.

3.Breakage Judgement: After sample fracture beam automatically stop moving.

MAIN FRAME CONSTRUCTION

1.4 Column 2 ball screw driven & double spaces structure, upper for tensile & lower for compression (can be customized).

2.Machine base hosts the lower crosshead, the servomotor as well as the screw-ball driven mechanical transmission system.

3.Adopting ball screw drive, realize no clearance in transmission, make sure the precision control of the test force and test speed.

4.Precision AC Servo motor, AC Drive and High resolution photoelectric encoder for displacement measurement.

SAFETY DEVICE

1.Provision for calculations of parameter such as ultimate stress, percentage of elongation, cross section area peak load.

2.Stroke protection: Over travel safety by fixed and adjustable limit switches at both ends.

3.Overload protection: by system setting.

4.Emergency stop: by emergency push button.

5.All machine of frame size is different as per capacity.
