Touch Screen Micro Vickers Hardness Tester (HT-1000AT)

Touch Screen Micro Vickers Hardness Tester (HT-1000AT)

Product Details:

  • Dimension (L*W*H) 530X200X530 Millimeter (mm)
  • Power Supply AC220V5% 50-60Hz
  • Machine Weight 35 Kilograms (kg)
1 INR/Number
X

Touch Screen Micro Vickers Hardness Tester (HT-1000AT) Price And Quantity

  • 1 Number
  • 1 INR/Number

Touch Screen Micro Vickers Hardness Tester (HT-1000AT) Product Specifications

  • AC220V5% 50-60Hz
  • 35 Kilograms (kg)
  • 530X200X530 Millimeter (mm)

Touch Screen Micro Vickers Hardness Tester (HT-1000AT) Trade Information

  • Cheque Telegraphic Transfer (T/T)
  • 1 Number Per Day
  • 1 Week
  • All India

Product Description

Features

MANUAL EYEPIECE :Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on LCD screen by entering the indentation diagonal length.

CAMERA PORT :Machine equipped with dual optical channel, one optical channel for 10X eyepiece and another optical channel is for camera by which machine can be upgraded into computerized/ computer controlled model. Both optical channel works simultaneously.

ILLUMINATION SYSTEM :Halogen illumination unit with adjustable intensity gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

TEST FORCE :Wide range of test force (10gm to 1000gm) can be selected with external force selection knob. The test force is automatically displayed on the 7 inch LCD touch display.

DATA OUTPUT :Equipped with built is thermal printer to take the print out the hardness result USB port is also available to get the data in pendrive.

AUTO TURRET MECHANISM :Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using touch panel.

Z-AXIS LIFTING SYSTEM :Side-Ways lifting system makes the z-axis movement more stable and accurate.

LCD TOUCH SCREEN PANEL :7 Inch LCD touch screen can visually display the hardness value, hardness conversion (4 conversion scales can be displayed at the same time), test force, dwell time, statistical data, upper & lower limit and brightness of optical system.

EMERGENCY SWITCH :Equipped with emergency stop switch.
