Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000AT with Vidas 2.0)

Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000AT with Vidas 2.0)

Product Details:

  • Power Supply AC220V5% 50-60Hz
  • Dimension (L*W*H) 530X200X530 Millimeter (mm)
  • Machine Weight 35 Kilograms (kg)
1 INR/Number
X

Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000AT with Vidas 2.0) Price And Quantity

  • 1 INR/Number
  • 1 Number

Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000AT with Vidas 2.0) Product Specifications

  • AC220V5% 50-60Hz
  • 35 Kilograms (kg)
  • 530X200X530 Millimeter (mm)

Computerized Touch Screen Micro Vickers Hardness Tester (HT-1000AT with Vidas 2.0) Trade Information

  • Cheque Telegraphic Transfer (T/T)
  • 1 Number Per Day
  • 1 Week
  • All India

Product Description

Features

MANUAL EYEPIECE :Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on LCD screen by entering the indentation diagonal length.

CAMERA PORT :Machine equipped with dual optical channel. 5 MP USB Camera is connected to one of the dual optical channels, other optical channel is for 10X eyepiece. Both optical channel works simultaneously.

ILLUMINATION SYSTEM :Halogen illumination unit with adjustable intensity gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.

TEST FORCE :Wide range of test force (10gm to 1000gm) can be selected with external force selection knob. The test force is automatically displayed on the 7 inch LCD touch display.

DATA OUTPUT :Equipped with built-in thermal printer to take the print out the hardness result. USB port is also available to get the data in pendrive. RS232 port is available to connect the machine with PC.

AUTO TURRET MECHANISM :Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using touch panel.

Z-AXIS LIFTING SYSTEM :Side-Ways lifting system makes the z-axis movement more stable and accurate.

LCD TOUCH SCREEN PANEL :7 Inch LCD touch screen can visually display the hardness value, hardness conversion (4 conversion scales can be displayed at the same time), test force, dwell time, statistical data, upper & lower limit and brightness of optical system.

EMERGENCY SWITCH :Equipped with emergency stop switch.
